High Brightness Security Narrow Bezel Video Wall Displays FHD 1920x1080 Resolution 55"

Product Categories
Shenzhen Boyou Technology Co., LTD.
Contact Now

High Brightness Security Narrow Bezel Video Wall Displays FHD 1920x1080 Resolution 55"

  • 1
  • 2

Brand Name : XUNSHINA

Model Number : XS460-5500HD-SNL3

Certification : CE/ROHS/FCC

Place of Origin : China

MOQ : 4pcs

Payment Terms : T/T, L/C, Western Union

Supply Ability : 3000pcs per month

Delivery Time : 3-7 working days after payment

Packaging Details : Inner package: honeycomb carton with EPE foam full covering, Outer package: 4 in 1 plywood case

Product Name : LCD Splicing Wall

H/V View Angle : 178 ̊ /178 ̊ H/V

Size of Screen : 55" Samsung panel

Backlit : LED backlight

Display Area : 1209.6×680.4mm

Response Time : Not more than 8ms

Contrast : 4000:1

Color Depth : 16.7M

Contact Now

3.5mm Bezel LCD Video Wall Display , 55 inch Ultra Narrow LCD Splicing Wall

Description of lcd video wall
1. The image border optional compensation or cover , support roaming digital signals,bloom stretching ,cross-screen display ,a variety of plans to set up and run the display ,full HD real -time signal processing
2. Beautiful wall structure design, be convenient for installation and maintenance
3. Remote control function: by RS232 port and Ethernet connection for remote operation
4. Embedded 3D video bright separation circuit unit

Specifications

Model No. XS460-5500HD-SNL3
LCD Size 55" Samsung panel
Resolution 1920(H)x1080(V)
Pixel pitch 0.630(H)x0.630(V)
Backlight LED
Brightness(typical) 500cd/m²
Contrast 4000 : 1
Viewing angel (H/V) 178° / 178°
Color depth 16.7M
Response time <8ms
Display area 1209.6(H)×680.4(V)
Bezel 3.5mm
Interface CVBS In / Out (BNC ) 1/1
VGA In / Out 1/0
DVI In / Out 1/0
HDMI In/Out 1/0
DEBUG(USB) 1/0
Control IR remote control Yes
RS-232 In/Out 1/2
Physical parameter Dimension 1213.5mm(W) x684.3mm(H) x118mm(D)
Frame color Black
Frame material Metal
Net weight 30Kg
Power Power consumption ≦250W
Standby <1W
Power supply AC 100V-240V, 50/60Hz,Universal,±10%
Environment Operating humidity 20-90% RH(no condensation)
Storage humidity 10-90% RH (no condensation)
Operating temperature 0 ~ 50° C / 32 ~ 122° F
Storage temperature -20 ~ 60° C / -4 ~ 140° F
Accessory Standard accessories Power cable(1.8m, User manual, Warranty card, Quality certificate
Optional accessories Wall mounted brackets, floor stand brackets, cabinet
*design and specifications are subject to changes without prior notice

Applications

1.Education and Conference System
2.Safety Monitoring System of Mining and Energy Industry
3.Commercial Industry
Used in the display terminal of commercial industry, such as advertising, media, product presentations
4.Financial Industry
Used in the information display terminal of financial industry, such as stock and security market. .
5.Transportation Industry
Used in the information display terminal of transportation industry, such as airports, ports, metro, highway.
6.Management and Control System
Used in the display terminal of management and control system such as fire-fighting, meteorology, maritime, food prevention, transportation hub
